NiMH Battery Dedicated Charger Module 1.5V, 3V, 4.5V Charging Module Board

  • $5.08
  • NiMH Battery Dedicated Charger Module 1.5V, 3V, 4.5V Charging Module Board

    Product Name: 1A 1.2V 2.4V 3.6V NiMH Battery Dedicated Charger 1.5V 3V 4.5V CC/CV Charging Module Board

    Packing list:

    1 to 3 Cells Nickel Metal Hydride (NiMH) batteries Charger Module

    (Please choose the parameters you need when purchasing)

    *Kindly Reminder: This module is only for NiMH batteries, it will not suitable for Li-Ion or LiPO batteries.

    Description:

    1-Cell(1S) 1.5V Version:

    Input voltage : DC 3.5V-6V(Recommend DC 3.7V/3.8V/4.5V/5V)

    Charging voltage : 1.5V

    Charging current : 1A

    2-Cell(2S) 3V Version:

    Input voltage: DC 3.7-6V(Recommend DC 3.7V/3.8V/4.5V/5V)

    Charging voltage: 3V

    Charging current: 1A

    3-Cell(3S) 4.5V Version:

    Input voltage : DC 5-6V(Recommend DC 5V)

    Charging voltage : 4.5V

    Charging current : 1A

    Precharge Conditioning for reviving deeply discharged cells and minimizing heat dissipation during the initial stage of charge.

    Constant-Current/Constant-Temperature operation with thermal regulation to maximize charge rate without risk of overheating

    Automatic Low-Power Sleep Mode when the input supply voltage is removed

    Maintenance Charge Mode(Timer Termination)

    Automatic Recharge

    Operating ambient temperature:  -40° to +85°

    Storage temperature :  -65° to +125°

    Size 30mm x 15mm x 2.7mm

    Weight : 1.8g(With Terminal),1.4g(No Terminal)

    Applications:

    GPI Case 1 (Please ask for assistance)

    Gameboy Color

    Gameboy Advance

    Toy Cars

    Digital Cameras

    Portable Solar Charging Blocks

    Bluetooth Device Applications

    Audio Equipment

    Electronic Dictionaries

    Portable Devices

    Led indicator :

    Bright: Charging; Off: full; If you want to increase the brightness of the LED, change the resistor R5.

    • Ex Tax:$5.08

    • 2 or more $3.58
    • 4 or more $2.84
    • 8 or more $2.47
    • 16 or more $2.28
    • 32 or more $2.06
    • Product Code: nimh-charging-module
    • Availability: 1499
